Galaxy GX1201-T Single-Head Embroidery Machine

The Galaxy Innovation Model is a single-head embroidery machine built for large-format work. Unlike standard machines limited by fixed mold sizes, its embroidery area can be customized to suit large-sized projects with options up to 800×1700mm.

For machines with an extremely large Y-axis stroke, this model uses long shaft transmission instead of belt transmission, delivering smoother, more precise operation and a longer service life. It also features an aluminum head that separates from the horse head lighter, more precise, and easier to maintain, while opening up possibilities for additional device installations.

Key Features:

• Customizable embroidery area (up to 800×1700mm)
• Long shaft transmission for extra-large Y-axis stroke machines
• Detachable, lightweight aluminum head for easier maintenance and expansion
• Single-head design, 12/15 needles

Key Specifications

• Heads: 1
• Needles: 12
• Maximum embroidery area: 800 × 1700mm (31.5" × 66.9") — largest of 4 size options

• Net/Gross weight: 150/200 kg (smallest) up to 350/400 kg (largest)
• Packing size: 980×1130×890mm up to 2000×1250×1200mm depending on size chosen
